Automatic Six Head Servo Filling Line and Capping Machine
Home Automatic Six Head Servo Filling Line and Capping Machine
Automatic Six Head Servo Filling Line and Capping Machine
Automatic
Six Head Servo Filling Line and Capping Machine
The Automatic Six Head Servo Filling Line with CappingMachine is a high-performance liquid packaging solution designed for
filling and sealing containers with precision and speed. Equipped with six
servo-controlled filling heads, this machine ensures accurate volume control,
hygienic filling, and efficient throughput. Integrated with an automatic
capping system, it offers a seamless solution from filling to closure—making it
ideal for industries requiring high-volume, contamination-free packaging.
This machine is widely used in pharmaceutical, food &beverage, cosmetics, chemical, lubricant, and personal careindustries. With advanced PLC controls, HMI interface, drip-free nozzles, and
adjustable bottle guides, it guarantees minimal downtime, reduced wastage, and
consistent output across batches.
Applications
of Six Head Servo Filling & Capping Line
Perfect for filling and capping:
- Pharmaceuticals:
Syrups, tonics, suspensions
- Cosmetics:
Shampoos, lotions, hair oils, gels
- Edible
Products: Cooking oil, sauces, vinegar, juices
- Chemicals:
Detergents, pesticides, disinfectants
- Lubricants:
Engine oils, brake fluids, greases
- Dairy:
Flavored milk, cream, buttermilk
Key
Features with Uses
|
Feature |
Uses/Benefits |
|
Six Servo-Controlled Filling Heads |
Offers precision filling with high-speed operation and uniform output |
Integrated Automatic Capping |
Ensures tight, consistent sealing of bottles, reducing
manual labor |
|
Touchscreen HMI & PLC Control |
Enables easy operation, recipe storage, and parameter
changes |
|
No-Container-No-Fill & No-Cap |
Prevents spillage and ensures safety and
cost-effectiveness |
|
Drip-Free Nozzles |
Maintains hygiene and avoids product wastage |
|
Quick Changeover Design |
Facilitates fast bottle and cap type change, improving
uptime |
|
SS 304/316 Construction |
Corrosion-resistant and ideal for food/pharma-grade
applications |
|
Automatic Bottle Positioning |
Aligns containers precisely for smooth filling and capping
operations |
|
Vibration-Free Conveyor System |
Ensures smooth movement of containers through the entire
filling-capping line |
|
Variable Speed Drive (VFD) |
Adjusts line speed based on production requirements and
operator comfort |
Key
Points
- Servo technology ensures ±0.5% filling accuracy
- Designed
for continuous 24x7 operations in industrial environments
- Ideal
for medium to high-volume production plants
- Compatible
with round, square, and custom bottle shapes
- Fill
range: 100ml to 5 liters (customizable)
- Output
capacity: Up to 2400-3600 bottles/hour (depending on fill size and bottle
type)
- Automatic
cap elevator or cap unscrambler optional
- Clean-In-Place
(CIP) system supported for food/pharma use
- Strong
SS frame with adjustable legs for stability
- Safety
enclosure with interlock system (optional)
Top 10
FAQs on Automatic Six Head Servo Filling & Capping Machine
- What
is a six-head servo filling and capping machine?
It is an automated system that fills six containers simultaneously with liquid and seals them using a capping unit. - Which
products are suitable for this machine?
It handles liquids of various viscosities, including oil, shampoo, syrup, detergent, lubricants, and more. - What
kind of caps can be used with this system?
ROPP, screw caps, flip-top caps, press-on caps, and even pump caps (with attachments). - Is
it suitable for viscous liquids?
Yes. The servo-controlled pistons handle both low and high-viscosity liquids effectively. - Can
the machine handle different bottle sizes?
Absolutely, it supports quick changeover for multiple container sizes and shapes. - How
accurate is the filling process?
The system ensures ±0.5% accuracy, depending on the viscosity and container design. - Does
it support automatic cap feeding?
Yes. Cap unscramblers or elevators can be integrated for full automation. - What
is the production output?
The machine can process up to 2400-3600 bottles per hour, depending on the liquid and container size. - Is
it easy to operate and clean?
Yes, the system includes a user-friendly HMI panel and CIP support for cleaning. - Can
it be integrated into a full packaging line?
Yes, it can be synchronized with labeling, induction sealing, shrink sleeving, and carton packaging units.
Conclusion
The Automatic Six Head Servo Filling Line and CappingMachine is an all-in-one, efficient, and scalable solution for modern
liquid packaging. Its advanced automation, hygienic build, and high-speed
performance make it an indispensable asset for manufacturers seeking precision,
speed, and consistency.
